HYDRAFORE Y-60HF-C
3 in 1 multifunctional head: crimping pliers, cable cutter, sheet metal punch
| Technical parameters: | |
| Crimping / cable cutter / sheet metal punch head | |
| Model: | Y-60H |
| Pressure force: | 6 T |
| Hub: | 42mm |
| Crimp stamping: | 16, 25, 35, 50, 70, 95, 120, 150, 185, 240, 300mm2 |
| Stamp type: | Hexagonal |
| Cutting area (aluminium/copper) : | max. Ø40 mm |
| Punching area : | Ø22, 27, 34, 43, 49, 60mm |
| Weight: | 9kg |
| operating pressure | 700 bars |
| Hydraulic connection | HH-2-M |
| Recommended pump | B-700C |
| Shipping volume: | 5 4x18x60cm |
